Pipe Seals











Forecourt Solutions entry boot range is part of the comprehensive ChamberTite range. The range is designed to alleviate the problem of water ingress into containment chambers and sumps and tank and dispenser sumps on petroleum forecourts that have pipework and duct entries. The boot provides a watertight seal to the pipe and to the chamber wall.



Features & Benefits

• Waterproof Pipe and Duct Penetrations
• Installation on flat and round surfaces
• Fuel Compatible materials
• Nitrile rubber to BS2751
• Suitable for entries up to 15° from perpendicular
• Fully adjustable post installation
• Testable and Re-sealable
• Cable Entry Bulkhead watertighness tested to 2m water head.

Design Concept

Each entry boot within the range is sized to provide maximum flexibility for the different pipework systems commonly used. Pipe alignment in both horizontal and vertical planes is facilitated. Boot flexibility reduces stress transfer to containment chamber walls.

For further detailed product information see in individual product pages for downloads of Case Studies (CS), Drawings (DRG) and Installation Instructions (INS)

•

  ChamberTite Entry Boot 3/4" or 25mm CTB-0075

  3/4" or 25mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Chambers ..

  Price:
  TBA
•

  ChamberTite Entry Boot 1" or 32mm CTB-0100

  1" or 32mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Chambers an..

  Price:
  TBA
•

  ChamberTite Entry Boot 1 1/2" or 50mm c/w 3/4", 1" and 1 1/4" adapters CTB-3150

  1 1/2" or 50mm ChamberTite Entry Boot and reducer donuts for sealing pipe, cables and ducts into ..

  Price:
  £10.00
•

  ChamberTite Entry Boot 1 1/2" or 50mm CTB-0150

  1 1/2" or 50mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Ch..

  Price:
  TBA
•

  ChamberTite Entry Boot 2" or 63mm CTB-0200

  2" or 63mm ChamberTite Flexible Entry Boot for sealing pipe, cables and ducts into Containment Ch..

  Price:
  TBA
•

  ChamberTite Entry Boot 2 1/2" or 75mm CTB-0250

  2 1/2" or 75mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Ch..

  Price:
  TBA
•

  ChamberTite Entry Boot 3" or 90mm CTB-0300

  3" or 90mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Chambe..

  Price:
  TBA
•

  ChamberTite Entry Boot 4" or 110mm CTB-0400

  4" or 110mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Chambers a..

  Price:
  TBA
•

  ChamberTite Duct Boot- 4" or 110mm to 2" Pipe seal CTB-4520

  4" ChamberTite Duct Seal suitable for sealing a 100-110mm rigid or flexible duct into a watertigh..

  Price:
  TBA
•

  ChamberTite Duct Boot- 4" or 110mm CTB-7450

  4" ChamberTite Duct Seal suitable for sealing a 100-110mm rigid or flexible duct into a watertigh..

  Price:
  TBA
•

  Cable Entry Bulkhead suitable for 4" (110mm) Duct CTB-7450B

  4" ChamberTite Cable Entry Bulkhead or Duct Seal suitable for sealing a 100-110mm rigid or flexib..

  Price:
  TBA
•

  Cable Entry Bulkhead suitable for 1 1/2" (50mm) Duct to Seal up to 8 cable entries CTB-7450B15

  4" ChamberTite Duct Seal suitable for sealing a 1 1/2" or  50mm rigid conduit into a wa..

  Price:
  TBA
•

  Cable Entry Bulkhead suitable for 2" (63mm) Duct to Seal up to 8 cable entries CTB-7450B2

  4" ChamberTite Duct Seal suitable for sealing a 2" or  63mm rigid conduit into a watertight ..

  Price:
  TBA
•

  Cable Entry Bulkhead suitable for 3" (90mm) Duct to Seal upto 8 cable entries CTB-7450B3

  4" ChamberTite Duct Seal suitable for sealing a 3" or  90mm rigid conduit into a watert..

  Price:
  TBA
•

  ChamberTite Entry Boot 5" or 125mm CTB-0500

  5" or 125mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Chamb..

  Price:
  TBA
•

  ChamberTite Entry Boot 5 1/2" or 140mm CTB-0550 - NEW

  51/2" or 140mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Ch..

  Price:
  TBA
•

  Cable Entry Bulkhead suitable for 5" (125mm) Duct to Seal up to 9 cable entries CTB-0500B

  5" ChamberTite Duct Seal suitable for sealing a 5" or  125mm rigid or flexible conduit ..

  Price:
  TBA
•

  ChamberTite Entry Boot 6" or 160mm CTB-0600

  6" or 160mm ChamberTite Entry Boot for sealing pipe, cables and ducts into Containment Chamb..

  Price:
  TBA
•

  Cable Entry Bulkhead suitable for 6" (160mm) Duct to Seal upto 9 cable entries CTB-0600B

  6" ChamberTite Duct Seal suitable for sealing a 6" or  160mm rigid or flexible conduit ..

  Price:
  TBA
•

  ChamberTite Duct Boot 7" or 180mm CTB-0700

  7" or 180mm ChamberTite Duct Boot for sealing pipe, cables and ducts into Containment Chambers an..

  Price:
  TBA
